3-20x50 PM II Ultra Short LP MSR2 1cm cw DT35 MTC LT / ST ZC CT

Article number: 667-911-822-F2-E9

The 3-20x50 PM II Ultra Short is the logical further development of the 3-20x50 PM II. It offers the largest field of view in its class while being the shortest and lightest riflescope in this performance segment.

Dynamic Static
Short Distance Medium Distance Long Range Extreme Long Range

€4,760.00*

Prices incl. VAT plus shipping costs

Reticle
Find store
Store Locator

Unbeaten in its class

The 3-20x50 PM II Ultra Short is the logical further development of the 3-20x50 PM II. It offers the largest field of view in its class while being the shortest and lightest riflescope in this performance segment. With a length comparable to the legendary 3-12x50 PM II, it is the ideal upgrade for DMR systems and sniper platforms.

Its extremely compact design is particularly suited for semi-automatic rifles with short rails in combination with night-vision devices, yet it can also be used on bolt-action rifles up to .50 caliber. The 3-20x50 PM II Ultra Short demonstrated its capability in the US Army’s CSASS program, won jointly with Heckler & Koch. Since then, the Ultra Short has been in service with the US Air Force, as well as Canadian, Spanish, and various police and anti-terror units.

In addition to its exceptionally wide field of view, the Ultra Short offers a large exit pupil, high optical resolution, and excellent transmission. Its robust construction is built for extreme operational conditions, from low temperatures to severe shock loads. In a firing simulator, it successfully withstood more than 30,000 rounds at accelerations of several thousand g.

0 of 0 reviews

Leave a review!

Share your experiences with other customers.

  1. Length @ 0 dpt (mm | in): 343 | 13.50
  2. Main tube diameter (mm | in): 34 | 1.34
  3. Mounting system: Ring mount
  4. Weight (g | oz): 920 | 32.45
  5. Magnification: 3–20
  6. Internal objective diameter (mm | in): 50 | 1.97
  7. Field-of-view (m/100 m) | (ft/100 yd): 12.98–2.1 | 39.00–6.30
  8. Exit pupil diameter (mm | in): 11.4–2.5 | 0.45–0.10
  9. Eye relief distance (mm | in): 90 | 3.54
  10. Transmission (%): 90
  11. Focal Plane: 1
  12. Diopter adjustment (dpt): –3 to +2
  13. Parallax adjustment (m | yd): 25 – ∞ | 27.34 – ∞
  14. Illumination steps: 11
  15. Temperature – Function (°C | °F): –46 to +63 | –51 to +142
  16. Outer diameter objective (mm | in): 57 | 2.24
  17. Outer diameter ocular (mm | in): 50 | 1.97
  18. Waterproof (m | ft): 3 | 9.84
  19. Click value: 0.1 mrad
  20. Adjustment range elevation: 35 mrad
  1. Illumination color: red
  2. Reticle
  1. Seitenverstellweg 219
  2. Turret Configuration DT35 MTC LT / ST ZC CT (0.1 mrad)
  3. Turret rotation clockwise (cw)

Data & Downloads

  1. Main tube diameter (mm | in): 34 | 1.34
  2. Maximalvergroesserung 20
  3. Variante Standardausführung
  4. Bildebene-Auswahl 1. Bildebene - Glas (FFP)
  5. Kappe Tenebraex
  6. Magnification: 3–20
  7. Illumination color: red
  8. Temperature – Function (°C | °F): –46 to +63 | –51 to +142
  9. Variant / Option 1 6
  10. Batterie CR2032
  11. Outer diameter objective (mm | in): 57 | 2.24
  12. TypBezeichnung 3-20x50 PM II
  13. Exit pupil diameter (mm | in): 11.4–2.5 | 0.45–0.10
  14. Weight (g | oz): 920 | 32.45
  15. Internal objective diameter (mm | in): 50 | 1.97
  16. Length @ 0 dpt (mm | in): 343 | 13.50
  17. Turret rotation clockwise (cw)
  18. CleaningKit Optik Cleaning Kit Pro
  19. Illumination steps: 11
  20. Eye relief distance (mm | in): 90 | 3.54
  21. Diopter adjustment (dpt): –3 to +2
  22. Parallax adjustment (m | yd): 25 – ∞ | 27.34 – ∞
  23. Reticle MSR2
  24. Focal Plane: 1
  25. Variant / Option 2 911
  26. Variant / Option 5 E9
  27. Transmission (%): 90
  28. Ausfuehrung ZF mit Beleuchtung als Sonderausführung
  29. Outer diameter ocular (mm | in): 50 | 1.97
  30. Rohrkoerper LM-Rohr ohne Schiene, D34mm
  31. Adjustment range elevation: 35 mrad
  32. Variant / Option 3 822
  33. Mounting system: Ring mount
  34. Variant / Option 4 F2
  35. Seitenverstellweg 219
  36. Click value: 0.1 mrad
  37. Minimalvergroesserung 3 | 9.84
  38. Color: black
  39. Turret Configuration DT35 MTC LT / ST ZC CT (0.1 mrad)
  40. Field-of-view (m/100 m) | (ft/100 yd): 12.98–2.1 | 39.00–6.30
  41. Waterproof (m | ft): 3 | 9.84
