3-12x50 Klassik LM L3 1cm cw ASV / Klassik CT

Article number: 644-811-482-40-05A02

The 3-12x50 Klassik combines rugged construction with high precision. Its design is identical to the legendary 3-12x50 PM II riflescope and offers the same optical quality.

€1,580.00*

Prices incl. VAT plus shipping costs

Reticle
Find store
Store Locator

With its magnification of up to 12x zoom the 3-12x50 Klassik is suited ideally for close ranges as well as for hunting at longer distances. The 50 mm objective offers an excellent optical performance when facing low light conditions. While being the basis of our world famous 3-12x50 PM II USMC (U.S. Marine Corps) version it is perfect for hunts abroad under conditions that are very much different from the conditions prevailing in their hunting territories at home.

0 of 0 reviews

Leave a review!

Share your experiences with other customers.

  1. Length @ 0 dpt (mm | in): 350 | 13.78
  2. Main tube diameter (mm | in): 30 | 1.18
  3. Mounting system: Ring mount
  4. Weight (g | oz): 640 | 22.58
  5. Magnification: 3–12
  6. Internal objective diameter (mm | in): 50 | 1.97
  7. Field-of-view (m/100 m) | (ft/100 yd): 11.09–3.4 | 33.30–10.20
  8. Exit pupil diameter (mm | in): 14.4–4.2 | 0.57–0.17
  9. Eye relief distance (mm | in): 90 | 3.54
  10. Transmission (%): 90
  11. Focal Plane: 1
  12. Diopter adjustment (dpt): –3 to +2
  13. Parallax adjustment (m | yd): 100 | 109.36
  14. Illumination steps: 11
  15. Temperature – Function (°C | °F): –25 to +63 | –13 to +142
  16. Outer diameter objective (mm | in): 57 | 2.24
  17. Outer diameter ocular (mm | in): 43 | 1.70
  18. Waterproof (m | ft): 3 | 9.84
  19. Click value: 1 cm/100 m
  20. Adjustment range elevation: 48 cm/100 m
  1. Illumination color: red
  2. Reticle
  1. Turret Configuration ASV / Klassik CT (1 cm)
  2. Turret rotation clockwise (cw)

Data & Downloads

  1. Kappe Bikini
  2. Variante Standardausführung
  3. Field-of-view (m/100 m) | (ft/100 yd): 11.09–3.4 | 33.30–10.20
  4. Length @ 0 dpt (mm | in): 350 | 13.78
  5. Click value: 1 cm/100 m
  6. Magnification: 3–12
  7. TypBezeichnung 3-12x50
  8. Bildebene-Auswahl 1. Bildebene - Glas (FFP)
  9. Outer diameter ocular (mm | in): 43 | 1.70
  10. Illumination color: red
  11. Main tube diameter (mm | in): 30 | 1.18
  12. Variant / Option 1 6
  13. Batterie CR2032
  14. Temperature – Function (°C | °F): –25 to +63 | –13 to +142
  15. Rohrkoerper LM-Rohr ohne Schiene, D30mm
  16. Outer diameter objective (mm | in): 57 | 2.24
  17. Adjustment range elevation: 48 cm/100 m
  18. Internal objective diameter (mm | in): 50 | 1.97
  19. Variant / Option 2 811
  20. Turret rotation clockwise (cw)
  21. Illumination steps: 11
  22. Weight (g | oz): 640 | 22.58
  23. Eye relief distance (mm | in): 90 | 3.54
  24. Variant / Option 3 482
  25. Variant / Option 5 05A02
  26. Diopter adjustment (dpt): –3 to +2
  27. Maximalvergroesserung 12
  28. Focal Plane: 1
  29. CleaningKit Cleaning Pouch
  30. Exit pupil diameter (mm | in): 14.4–4.2 | 0.57–0.17
  31. Transmission (%): 90
  32. Ausfuehrung ZF mit Beleuchtung als Sonderausführung
  33. Parallax adjustment (m | yd): 100 | 109.36
  34. Reticle L3
  35. Mounting system: Ring mount
  36. Variant / Option 4 40
  37. Turret Configuration ASV / Klassik CT (1 cm)
  38. Minimalvergroesserung 3 | 9.84
  39. Color: black
  40. Waterproof (m | ft): 3 | 9.84
